6 Technical data
6.1 General specifications
Parameter Value
Operating pressure 600 kPa (6 bar)
Operating voltage 3x 24 V DC, 4.5 A
Digital inputs/outputs
Inputs: 06+10+07
Outputs: 07+06+04
Max. 24 V DC
Max. 2 A per output
Max. 4 A total
Electrical connection 24-pin IEEE-488 socket (SysLink)
Pneumatic connection Plastic tubing with 6 mm outside diameter
Compressed air consumption at 600 kPa (continuous cycle) 10 l/min
Dimensions 1050 mm x 700 mm x 1240 mm
Subject to change
