Festo MPS System 203 Basic - Terminal assignment tables, Joining station; Terminal assignment tables, Joining station (XG1)

MPS
®
System 203 Basic
44 © Festo Didactic 8064034
6.3 Terminal assignment tables, Joining station
6.3.1 Terminal assignment tables, Joining station (XG1)
Digital
Function SysLink Color Designation
I0 13 Gray-pink Workpiece at sbeginning of conveyor (1)
I1 14 Red-blue Workpiece at middle of conveyor (1)
I2 15 White-green Workpiece not at end of conveyor (1)
I3 16 Brown-green Distance sensor, digital
I4 17 White-yellow Workpiece at beginning of conveyor (2)
I5 18 Brown-yellow
I6 19 White-gray Workpiece not at end of conveyor (2)
I7 20 Gray-brown
Q0 1 White Conveyor belt (1) forward
Q1 2 Brown Conveyor (1) belt reverse
Q2 3 Green Retract deflector
Q3 4 Yellow Advance stopper
Q4 5 Gray Conveyor belt (2) forward
Q5 6 Pink Conveyor belt (2) reverse
Q6 7 Blue
Q7 8 Red
24 V A 9+10 Black 24 V power supply for outputs
24 V B 21+22 White-pink 24 V power supply for inputs
GND A 11 Brown-pink 0 V power supply for outputs
GND A 12 Purple 0 V power supply for outputs
GND B 23+24 White-blue 0 V power supply for inputs
Analog
Function D-SUB-15 Color Designation
AI0 8 Distance sensor, analog
Hinweis
Bei allen Vorzugsvarianten SPS sind Kabelbrücken von NOT-AUS auf Bit 1.5 gesteckt.
