6.4 Terminal assignment table, Sorting station
Digital
Function SysLink Color Designation
I0 13 Gray-pink Workpiece at beginning of conveyor
I1 14 Red-blue Deflector 1 advanced
I2 15 White-green Chute full
I3 16 Brown-green Deflector 2 advanced
I4 17 White-yellow Workpiece detected
I5 18 Brown-yellow Workpiece not black
I6 19 White-gray Workpiece metallic
I7 20 Gray-brown
Q0 1 White Conveyor belt forward
Q1 2 Brown Advance deflector 1
Q2 3 Green Advance deflector 2
Q3 4 Yellow Retract stopper
Q4 5 Gray
Q5 6 Pink
Q6 7 Blue
Q7 8 Red
24 V A 9+10 Black 24 V power supply for outputs
24 V B 21+22 White-pink 24 V power supply for inputs
GND A 11 Brown-pink 0 V power supply for outputs
GND A 12 Purple 0 V power supply for outputs
GND B 23+24 White-blue 0 V power supply for inputs
Note
Cable jumpers are connected from emergency off to bit 1.5 for all standard PLC versions.
