Festo MPS System 203 Basic - Terminal assignment tables, Distributing;Conveyor station with signal column at the control panel

MPS
®
System 203 Basic
42 © Festo Didactic 8064034
6.2 Terminal assignment tables, Distributing/Conveyor station with signal column at the control panel
Digital (station XG1)
Function SysLink Color Designation
I0 13 Gray-pink Workpiece at beginning of conveyor
I1 14 Red-blue Workpiece at middle of conveyor
I2 15 White-green Workpiece not at end of conveyor
I3 16 Brown-green
I4 17 White-yellow Slide retracted
I5 18 Brown-yellow Slide advanced
I6 19 White-gray Magazine empty
I7 20 Gray-brown
Q0 1 White Conveyor belt forward
Q1 2 Brown Conveyor belt reverse
Q2 3 Green Retract deflector
Q3 4 Yellow
Q4 5 Gray Advance slide
Q5 6 Pink
Q6 7 Blue
Q7 8 Red
24 V A 9+10 Black 24 V power supply for outputs
24 V B 21+22 White-pink 24 V power supply for inputs
GND A 11 Brown-pink 0 V power supply for outputs
GND A 12 Purple 0 V power supply for outputs
GND B 23+24 White-blue 0 V power supply for inputs
