Technical data
12 Technical data
12.1 Technical data, mechanical
MS6-SV-E
Type of mounting In-line installation
with accessories
Design Piston seat has no underlap
Position sensing principle Piston magnet principle
Reset method mechanical spring
Mounting position any
Sound pressure level [dB(A)] 75 with silencer UOS-1
Environmental conditions
Shock resistance Shock test with severity level 2 in accordance with
EN 60068-2-27
Vibration resistance with severity level 2 in accordance with EN 60068-2-6
Degree of protection
Degree of protection IP65
Note with multi-pin plug socket NECA
Materials
Housing Die-cast aluminium
Seal NBR
Tab. 9: Technical data, mechanical
12.2
Technical data, pneumatic
MS6-SV-E
Pneumatic port 1, 2 [G] 1/2
Pneumatic port 3 [G] 1
Pilot air supply internal
Exhaust function cannot be throttled
Manual override none
Type of control piloted
Valve function 3/2-way valve, single solenoid, closed
Soft-start function
