Festo MS6 SV E 10V24 Series Operating Instructions

Festo — MS6(N)-SV-...-E-10V24 — 2021-11e
Technical data
27
MS6-SV-E
Medium
Operating medium Compressed air according to ISO 8573-1:2010 [7:4:4]
and inert gases
Note lubricated operation possible, required for further
operation
Temperature
Medium [°C] -10 … +50
Environment [°C] -10 … +50
Bearing [°C] -10 … +50
Operating pressure
Operating pressure [bar] 3.5 … 10
Residual pressure in normal
operation
[bar] 0 (no residual pressure)
Residual pressure in the event
of error
[bar] £ 0.4 (at p1 = 10 bar and flow control fully open)
C value [l/(s bar)] 19.3
B value 0.21
Characteristic flow rate values
Standard nominal flow rate
1 } 2
[l/min] 4300 (at p1 = 6 bar, p2 = 5 bar)
Standard flow rate 2 } 3 [l/min] 9000 (at p1 = 6 bar
Standard flow rate 2 } 3 in the
event of a critical fault
[l/min] ³ 6000 (at p1 = 6 bar)
Switch-through point Approx. 50% of p1
Filling flow adjustable by flow control valve
minimum pause time after
exhaust
[s] ³ 2
Tab. 10: Technical data, pneumatic
12.3
Technical Data, Electrical
MS6-SV-E
Actuation type Electrical
Switching frequency [Hz] £ 0.5
Electrical connection Sub-D, 9-pin, only with multi-pin plug sockets NECA-
S1G9-P9-MP...
