22
Festo — MS6(N)-SV-...-E-10V24 — 2021-11e
Commissioning
Terminal in multi-pin
plug socket NECA-...
I/O I/O allocation
5 A5 Contact for automatic
start operating mode
–
6 S34 Contact for automatic
start or monitored start
operating mode
Input 0 V/24 V (EN 61131-2 type 2)
7 - -
8 +L1 Operating voltage +24 V DC ±10%
9 M GND
Tab. 6: Terminal assignment
7
Commissioning
For easier commissioning, we recommend installation of a reset button (normally closed) in the power
supply circuit. This simplifies a reset in case of error.
The commissioning description is graphically supported with the following diagrams:
– with multi-pin plug socket NECA-S1G9-P9-MP1
è
Fig. 20.
–
with multi-pin plug socket NECA-S1G9-P9-MP3/MP5
è
Fig. 23.
The diagrams show the switching characteristics of the inputs and outputs in normal operation (if the
automatic start mode of operation has been set). The operator’s actions are marked in the diagram by
an arrow.
