Festo MS6 SV E 10V24 Series Operating Instructions

Festo — MS6(N)-SV-...-E-10V24 — 2021-11e
Product overview
7
Feature Code Type
Port size – AGC G3/8
– AGD G1/2
– AGE G3/4
– AQN NPT1/4
– AQP NPT3/8
– AQR NPT1/2
– AQS NPT3/4
Performance Level – E In accordance with EN ISO 13849-1, category 4
2-channel with self-monitoring, safety device in accordance
with EC Machinery Directive 2006/42/EC
Supply voltage – 10V24 24 V DC
Options
1)
– SO Open silencer
Pressure gauge/pressure
gauge alternative
1)
– AG Integrated pressure gauge
– A4 Adapter for EN pressure gauge ¼, without pressure gauge
– AD1 Pressure sensor with display, M8 plug, PNP, 3-pin
– AD2 Pressure sensor with display, M8 plug, NPN, 3-pin
– AD3 Pressure sensor with display, plug M12, PNP, 4-pin, ana-
logue output 4 … 20 mA
– AD4 Pressure sensor with display, plug M12, NPN, 4-pin, ana-
logue output 4 … 20 mA
Alternative pressure gauge
scaling
1)
– PSI psi scaling
– MPA MPa scaling
– BAR bar scaling
Multi-pin plug socket
1)
– MP1 Sub-D, 9-pin, screw terminal, without cable
Enable signals static (EN1 = 24 V, EN2 = 24 V)
– MP3 Sub-D, 9-pin, screw terminal, without cable
Enable signals static (EN1 = 0 V, EN2 = 24 V)
Detection of shorts across contacts possible
– MP5 Sub-D, 9-pin, screw terminal, without cable
Enable signals static (EN1 = 0V, EN2 = 24V)
Galvanic isolation of enable signals from the supply voltage
Type of mounting
1)
– WPB Mounting bracket for large mounting spacing
