Product-specific terms and abbreviations
The following product-specific abbreviations are used in this
manual:
Term/
abbreviation
Meaning
0-signal Input or output supplies 0 V
1-signal Input or output supplies 24 V
Drive In this manual the term ”Drive” represents the terms ”linear unit”
(DGP(I)(L)-...), ”cylinder” (DNC-...) or ”rotary drive” (DSMI ).
O Digital output
Cushioning stage The positioning behaviour is determined by the amplification and cushioning
stages. The cushioning stage serves for optimizing t he starting behaviour when
movement is made towards the end positions.
I Digital input
PLC, IPC Programmable logic controller/industrial PC
System parameter Characteristic value which describes both the system structure as well as the
features and components of the drive use d.
Parameter Parameters which must be set for opera ting the system. This includes the
cushioning stage, the amplification stage and the system parameters.
Teach procedure In the Teach procedure, the SPC11 checks the set parameters, learns the
position of the mechanical fixed stops a s well as various characteristic system
values and saves these in the integrated EE PROM.
Amplification stage The amplification stage influe nces e.g. the acceleration behaviour of the
drive. The amplification stage should usua lly be set in accordance with the
specifications in the manual “Drive-specific supplement”. If it is necessary to
optimize the positioning behaviour, only t he cushioning stage should be
modified.
