Festo SPC11 - Dgp(I)(L)-40

2. Parameters of the SPC11 for the DGP(I)(L)-...
2-36
Festo P.BE-SPC11 -DGP-EN en 0012NH
2.4.3 DGP(I)(L)-40-... in vertical operation
DGP(I)(L)-40-225 to ...-40-360 in vertical operation
DGP(I)(L)-40-225 DGP(I )(L)-40-300 DGP(I)(L)-40-360
MPYE-5-1/8- LF- 010B MPYE- 5-1/8- LF-010B MPYE- 5-1/8- LF- 010B
Mass [kg]
Amplification stage Cushioning stage System parameter Time upwards [s] Time downwards [s] Amplification stage Cushioning stage System parameter Time upwards [s] Time downwards [s] Amplification stage Cushioning stage System parameter Time upwards [s] Time downwards [s]
5 12 14 15
0.68 0.59
16 15 26
0.72 0.73
18 15 26
0.78 0.73
10 15 18 15
0.67 0.62
18 19 26
0.74 0.71
20 19 26
0.82 1.00
15 16 20 15
0.74 0.62
20 21 26
0.78 0.76
22 21 26
0.90 0.78
20 18 22 15
0.75 0.66
21 23 26
0.88 0.75
23 23 26
0.93 0.96
25 18 24 15
0.83 0.69
22 24 26
0.90 0.77
24 24 26
0.99 1.11
