Festo SPC11 - Dgp(I)(L)-40

2. Parameters of the SPC11 for the DGP(I)(L)-...
2-16
Festo P.BE-SPC11 -DGP-EN en 0012NH
2.3.3 DGP(I)(L)-40-... in horizontal operation
DGP(I)(L)-40-225 to ...-40-360 in horizontal operation
DGP(I)(L)-40-225 DGP(I )(L)-40-300 DGP(I)(L)-40-360
MPYE-5-1/8- H F-010B MPYE-5-1/8- H F-010B MPYE-5-1/8- H F-010B
Mass [kg] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s]
5 8 15 12 0.46 11 16 23 0.55 13 16 24 0.58
10 10 18 12 0.50 14 19 23 0.56 16 19 24 0.58
15 12 20 12 0.51 15 21 23 0.61 17 22 24 0.64
20 13 21 12 0.49 16 22 23 0.60 18 24 24 0.70
25 14 23 12 0.53 17 24 23 0.66 19 25 24 0.69
30 15 24 12 0.54 18 25 23 0.70 20 26 24 0.72
35 15 25 12 0.60 19 25 23 0.64 21 26 24 0.72
40 16 26 12 0.60 19 27 23 0.72 21 27 24 0.71
45 16 26 12 0.61 20 27 23 0.67 22 27 24 0.69
50 17 26 12 0.61 20 28 23 0.73 22 28 24 0.74
55 17 29 12 0.70 20 28 23 0.74 23 28 24 0.72
60 18 27 12 0.66 21 28 23 0.73 23 31 24 0.76
65 18 28 12 0.66 21 29 23 0.74 23 29 24 0.71
70 18 28 12 0.68 21 29 23 0.71 24 29 24 0.76
75 19 28 12 0.71 22 29 23 0.70 24 30 24 0.76
