Festo SPC11 - Dgp(I)(L)-32

2. Parameters of the SPC11 for the DGP(I)(L)-...
2-12
Festo P.BE-SPC11 -DGP-EN en 0012NH
2.3.2 DGP(I)(L)-32-... in horizontal operation
DGP(I)(L)-32-225 to ...-32-360 in horizontal operation
DGP(I)(L)- 32-225 DGP(I)(L)-32-300 DGP(I)(L)-32-360
MPYE-5-1/8- LF- 010B MPYE- 5-1/8- HF-010B MPYE- 5-1/8- HF-010B
Mass [kg] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s]
3 10 14 13 0.52 9 16 11 0.44 11 16 22 0.49
6 12 17 13 0.56 11 19 11 0.49 13 20 22 0.52
9 14 20 13 0.59 12 21 11 0.54 15 22 22 0.59
12 15 21 13 0.63 14 22 11 0.54 16 23 22 0.58
15 16 22 13 0.61 14 24 11 0.58 17 24 22 0.60
18 16 24 13 0.70 15 25 11 0.60 17 26 22 0.65
21 17 25 13 0.70 16 26 11 0.59 18 28 22 0.72
24 18 26 13 0.66 16 27 11 0.64 18 28 22 0.75
27 18 26 13 0.69 17 26 11 0.62 19 28 22 0.67
30 19 27 13 0.75 17 28 11 0.66 19 30 22 0.77
33 19 28 13 0.71 18 28 11 0.66 20 28 22 0.65
36 19 28 13 0.76 18 30 11 0.73 20 29 22 0.72
39 20 28 13 0.70 18 30 11 0.70 21 29 22 0.72
42 20 29 13 0.71 19 29 11 0.68 21 30 22 0.73
45 20 29 13 0.77 19 30 11 0.71 21 30 22 0.72
