Festo SPC11 - Page 43

2. Parameters of the SPC11 for the DGP(I)(L)-...
2-11
Festo P.BE-SPC11 -DGP-EN en 0012NH
DGP(I)(L)-25-1500 to ...-25-2000 in horizontal operation
DGP(I)(L)- 25-1500 DGP(I)(L)- 25-1750 DGP(I)(L)- 25-2000
MPYE-5-1/8- H F-010B MPYE-5-1/8- H F-010B MPYE-5-1/8- H F-010B
Mass [kg] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s]
2 25 25 26 1.24 27 24 26 1.20 28 28 27 1.39
4 28 26 26 1.06 29 27 26 1.21 31 27 27 1.36
6 29 28 26 1.08 31 29 26 1.23 32 30 27 1.41
8 30 30 26 1.17 32 30 26 1.28 33 31 27 1.43
10 31 31 26 1.16 33 32 26 1.33 34 32 27 1.46
12 32 32 26 1.21 34 33 26 1.36 35 33 27 1.50
14 33 33 26 1.23 34 34 26 1.39 36 34 27 1.52
16 33 34 26 1.28 35 34 26 1.41 36 35 27 1.56
18 34 34 26 1.29 35 35 26 1.44 37 36 27 1.60
20 34 35 26 1.32 36 36 26 1.48 37 37 27 1.63
22 34 36 26 1.34 36 37 26 1.51 38 37 27 1.65
24 35 36 26 1.36 36 37 26 1.53 38 38 27 1.70
26 35 37 26 1.40 37 38 26 1.57 38 38 27 1.70
28 35 37 26 1.42 37 38 26 1.59 39 39 27 1.74
30 36 38 26 1.46 37 39 26 1.63 39 39 27 1.76
