2. Parameters of the SPC11 for the DGP(I)(L)-...
2-10
Festo P.BE-SPC11 -DGP-EN en 0012NH
DGP(I)(L)-25-750 to ...-25-1250 in horizontal operation
DGP(I)(L)- 25-750 DGP(I)(L)-25-1000 DGP(I)(L)- 25-1250
MPYE-5-1/8- H F-010B MPYE-5-1/8- H F-010B MPYE-5-1/8- H F-010B
Mass [kg] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s]
2 18 20 13 0.63 21 22 24 0.79 23 22 25 0.90
4 20 23 13 0.68 23 24 24 0.80 26 25 25 0.93
6 21 25 13 0.73 25 26 24 0.85 27 27 25 0.97
8 23 26 13 0.76 26 28 24 0.89 28 29 25 0.99
10 23 28 13 0.76 27 29 24 0.87 29 30 25 1.02
12 24 29 13 0.78 27 30 24 0.91 30 31 25 1.07
14 25 29 13 0.81 28 31 24 1.01 30 32 25 1.10
16 25 30 13 0.84 29 32 24 0.98 31 33 25 1.10
18 26 31 13 0.86 29 32 24 1.01 32 33 25 1.15
20 26 31 13 0.89 29 33 24 1.00 32 34 25 1.18
22 27 33 13 0.93 30 33 24 1.05 32 35 25 1.21
24 27 33 13 0.90 30 34 24 1.07 33 35 25 1.22
26 27 33 13 0.95 31 34 24 1.08 33 36 25 1.24
28 28 34 13 0.99 31 35 24 1.11 33 37 25 1.30
30 28 34 13 0.98 31 37 24 1.18 34 37 25 1.30
