1. Summary of components
1-3
Festo P.BE-SPC11 -DGP-EN en 0012NH
1.1 General instructions
Warning
Faults in the system structure as well as incorrectly set
parameterscancausetheslidetomoveuncushionedinto
one of the end positions. This may cause damage to the
fixed stop or to the drive. Please obser ve the following
instructions in order to prevent such collisions.
S Set up the system with the greatest care. Observe at all
times the safety instruc tions and information in this
man u al as well as in the Sys t em m anu al type P.BE-
SP C 11-SYS.. . .
S Use only the matching components from Festo for setting
up and wiring the system. Only then can the correct func-
tioning of the system be guaranteed.
Please note
For operating the DGPI(L)- ... you will require the SPC11
type SPC11-MTS-AIF. For operating the DGP(L)-... with the
MLO-POT-...-TLF measuring system you will require the
SPC11 type SPC11-POT-TLF.
