Festo SPC11 - Dgp(I)(L)-63

2. Parameters of the SPC11 for the DGP(I)(L)-...
2-24
Festo P.BE-SPC11 -DGP-EN en 0012NH
2.3.5 DGP(I)(L)-63-... in horizontal operation
DGP(I)(L)-63-225 to ...-63-360 in horizontal operation
DGP(I)(L)- 63-225 DGP(I)(L)-63-300 DGP(I)(L)-63-360
MPYE-5-1/8- H F-010B MPYE-5-1/8- H F-010B MPYE-5-1/4-010B
Mass [kg] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s]
12 13 14 25 0.74 16 15 36 0.93 14 18 25 0.70
24 15 19 25 0.80 19 22 36 1.00 16 20 25 0.75
36 17 20 25 0.77 20 25 36 1.10 18 22 25 0.73
48 18 21 25 0.78 21 24 36 1.00 19 23 25 0.72
60 19 22 25 0.78 22 24 36 0.98 20 24 25 0.75
72 20 22 25 0.75 23 24 36 0.98 21 25 25 0.79
84 20 24 25 0.78 23 25 36 0.97 21 27 25 0.83
96 21 24 25 0.80 24 25 36 0.97 22 26 25 0.73
108 21 26 25 0.85 25 26 36 1.00 22 28 25 0.81
120 22 25 25 0.80 25 26 36 0.99 23 29 25 0.89
132 22 26 25 0.83 25 27 36 0.98 23 28 25 0.83
144 23 26 25 0.79 26 27 36 0.96 23 30 25 0.88
156 23 27 25 0.85 26 29 36 1.03 24 29 25 0.84
168 23 27 25 0.86 26 29 36 1.03 24 29 25 0.81
180 23 29 25 0.91 27 28 36 0.98 24 30 25 0.83
