2. Parameters of the SPC11 for the DGP(I)(L)-...
2-25
Festo P.BE-SPC11 -DGP-EN en 0012NH
DGP(I)(L)-63-450 to ...-63-600 in horizontal operation
DGP(I)(L)- 63-450 DGP(I)(L)- 63-500 DGP(I)(L)-63-600
MPYE-5-3/8- 010B MPYE-5-3/8- 010B MPYE-5-3/8- 010B
Mass [kg] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s]
12 14 19 24 0.79 15 20 24 0.80 18 18 35 0.87
24 17 21 24 0.76 18 21 24 0.79 20 23 35 0.93
36 18 23 24 0.75 19 23 24 0.79 21 24 35 0.96
48 19 25 24 0.86 20 25 24 0.91 22 26 35 0.95
60 20 26 24 0.79 21 26 24 0.92 23 27 35 0.95
72 21 27 24 0.91 22 27 24 0.87 24 28 35 1.00
84 21 28 24 0.86 23 27 24 0.84 25 28 35 0.97
96 22 29 24 0.85 23 29 24 0.87 25 30 35 1.02
108 23 29 24 0.87 24 30 24 0.90 26 29 35 0.97
120 23 29 24 0.82 24 30 24 0.91 26 30 35 0.98
132 23 32 24 0.95 25 30 24 0.89 27 30 35 0.99
144 24 30 24 0.83 25 31 24 0.94 27 31 35 1.01
156 24 31 24 0.90 25 31 24 0.91 27 31 35 1.07
168 24 32 24 0.96 26 31 24 0.91 28 32 35 1.04
180 25 31 24 0.88 26 31 24 0.92 28 32 35 1.02
