2. Parameters of the SPC11 for the DGP(I)(L)-...
2-26
Festo P.BE-SPC11 -DGP-EN en 0012NH
DGP(I)(L)-63-750 to ...-63-1250 in horizontal operation
DGP(I)(L)- 63-750 DGP(I)(L)-63-1000 DGP(I)(L)- 63-1250
MPYE-5-3/8- 010B MPYE-5-3/8- 010B MPYE-5-3/8- 010B
Mass [kg] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s]
12 20 20 36 1.00 23 22 37 1.23 26 25 38 1.49
24 22 23 36 1.03 26 24 37 1.21 28 26 38 1.46
36 24 25 36 1.01 27 26 37 1.23 30 27 38 1.43
48 25 27 36 1.06 28 28 37 1.27 31 29 38 1.54
60 26 28 36 1.07 29 29 37 1.27 32 30 38 1.48
72 27 28 36 1.09 30 30 37 1.29 32 31 38 1.51
84 27 30 36 1.08 30 31 37 1.32 33 32 38 1.54
96 28 31 36 1.16 31 31 37 1.31 33 33 38 1.58
108 28 31 36 1.10 31 33 37 1.37 34 34 38 1.59
120 29 31 36 1.10 32 32 37 1.32 34 34 38 1.57
132 29 32 36 1.12 32 33 37 1.37 35 34 38 1.57
144 29 33 36 1.19 33 33 37 1.34 35 35 38 1.58
156 30 32 36 1.13 33 34 37 1.36 35 35 38 1.59
168 30 33 36 1.18 33 34 37 1.40 36 35 38 1.60
180 30 34 36 1.19 34 34 37 1.36 36 36 38 1.62
