2. Parameters of the SPC11 for the DGP(I)(L)-...
2-27
Festo P.BE-SPC11 -DGP-EN en 0012NH
DGP(I)(L)-63-1500 to ...-63-2000 in horizontal operation
DGP(I)(L)- 63-1500 DGP(I)(L)- 63-1750 DGP(I)(L)- 63-2000
MPYE-5-3/8- 010B MPYE-5-3/8- 010B MPYE-5-3/8- 010B
Mass [kg] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s]
12 On request
24
36
48
60
72 34 32 38 1.78 36 33 39 2.05 37 34 39 2.35
84 35 33 38 1.80 37 33 39 2.05 38 35 39 2.35
96 35 34 38 1.84 37 35 39 2.11 39 35 39 2.36
108 36 35 38 1.83 38 35 39 2.11 39 36 39 2.38
120 36 35 38 1.85 38 36 39 2.09 40 36 39 2.38
132 37 35 38 1.83 38 37 39 2.13 40 37 39 2.41
144 37 36 38 1.86 39 37 39 2.13 40 38 39 2.42
156 37 36 38 1.84 39 38 39 2.16 41 39 39 2.43
168 38 36 38 1.86 40 37 39 2.13 41 39 39 2.45
180 38 37 38 1.90 40 39 39 2.19 41 40 39 2.48
