Festo SPC11 - Dgp(I)(L)-50

2. Parameters of the SPC11 for the DGP(I)(L)-...
2-20
Festo P.BE-SPC11 -DGP-EN en 0012NH
2.3.4 DGP(I)(L)-50-... in horizontal operation
DGP(I)(L)-50-225 to ...-50-360 in horizontal operation
DGP(I)(L)- 50-225 DGP(I)(L)-50-300 DGP(I)(L)-50-360
MPYE-5-1/8- LF- 010B MPYE- 5-1/8- HF-010B MPYE- 5-1/8- HF-010B
Mass [kg] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s]
8 15 13 26 0.80 14 16 25 0.64 16 17 25 0.75
16 17 19 26 0.81 16 19 25 0.68 18 19 25 0.77
24 19 20 26 0.78 18 21 25 0.69 20 21 25 0.75
32 20 21 26 0.75 19 22 25 0.71 21 23 25 0.79
40 21 22 26 0.82 20 24 25 0.73 22 24 25 0.77
48 22 23 26 0.82 21 24 25 0.76 23 25 25 0.82
56 22 24 26 0.82 21 25 25 0.74 23 26 25 0.85
64 23 24 26 0.76 22 26 25 0.78 24 26 25 0.82
72 23 25 26 0.81 22 27 25 0.81 24 27 25 0.81
80 24 26 26 0.86 23 27 25 0.80 25 27 25 0.83
88 24 26 26 0.83 23 28 25 0.80 25 28 25 0.85
96 25 27 26 0.86 23 28 25 0.79 25 29 25 0.88
104 25 28 26 0.87 24 29 25 0.78 26 29 25 0.91
112 25 28 26 0.88 24 30 25 0.86 26 29 25 0.87
120 26 28 26 0.84 24 29 25 0.81 26 31 25 0.90
