2. Parameters of the SPC11 for the DGP(I)(L)-...
2-21
Festo P.BE-SPC11 -DGP-EN en 0012NH
DGP(I)(L)-50-450 to ...-50-600 in horizontal operation
DGP(I)(L)- 50-450 DGP(I)(L)- 50-500 DGP(I)(L)-50-600
MPYE-5-1/4-010B MPYE-5-1/4-010B MPYE-5-3/8- 010B
Mass [kg] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s]
8 14 18 24 0.64 15 18 24 0.71 16 19 23 0.79
16 16 21 24 0.69 18 21 24 0.70 17 22 23 0.79
24 18 23 24 0.66 19 23 24 0.69 19 24 23 0.80
32 19 25 24 0.69 20 25 24 0.77 20 26 23 0.83
40 20 26 24 0.73 21 27 24 0.75 21 28 23 0.85
48 21 26 24 0.74 22 28 24 0.81 22 29 23 0.89
56 21 28 24 0.77 23 27 24 0.75 22 31 23 0.93
64 22 28 24 0.76 23 28 24 0.78 23 30 23 0.97
72 22 31 24 0.86 24 29 24 0.86 23 32 23 0.98
80 23 30 24 0.82 24 30 24 0.82 24 32 23 0.94
88 23 31 24 0.83 24 31 24 0.88 24 33 23 1.00
96 24 30 24 0.79 25 30 24 0.78 25 31 23 0.91
104 24 32 24 0.86 25 31 24 0.84 25 33 23 1.00
112 24 32 24 0.85 25 32 24 0.86 25 34 23 1.01
120 25 32 24 0.86 26 32 24 0.86 26 33 23 0.96
