2. Parameters of the SPC11 for the DGP(I)(L)-...
2-22
Festo P.BE-SPC11 -DGP-EN en 0012NH
DGP(I)(L)-50-750 to ...-50-1250 in horizontal operation
DGP(I)(L)- 50-750 DGP(I)(L)-50-1000 DGP(I)(L)- 50-1250
MPYE-5-3/8- 010B MPYE-5-3/8- 010B MPYE-5-3/8- 010B
Mass [kg] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s]
8 19 20 34 0.87 21 21 35 1.06 23 24 36 1.39
16 20 24 34 0.93 23 24 35 1.09 26 25 36 1.23
24 21 25 34 0.90 25 26 35 1.11 27 28 36 1.33
32 23 27 34 0.96 26 29 35 1.15 28 29 36 1.30
40 23 29 34 1.08 27 29 35 1.16 29 31 36 1.40
48 24 30 34 1.04 27 30 35 1.17 30 31 36 1.33
56 25 30 34 1.01 28 31 35 1.20 31 32 36 1.36
64 25 31 34 1.01 29 31 35 1.18 31 34 36 1.43
72 26 31 34 1.05 29 32 35 1.19 32 33 36 1.38
80 26 33 34 1.11 30 33 35 1.27 32 34 36 1.44
88 27 32 34 1.06 30 35 35 1.30 32 36 36 1.49
96 27 34 34 1.13 30 34 35 1.21 33 35 36 1.46
104 27 34 34 1.08 31 36 35 1.32 33 36 36 1.45
112 28 33 34 1.13 31 35 35 1.26 33 37 36 1.55
120 28 35 34 1.14 31 37 35 1.32 34 36 36 1.46
