2. Parameters of the SPC11 for the DGP(I)(L)-...
2-19
Festo P.BE-SPC11 -DGP-EN en 0012NH
DGP(I)(L)-40-1500 to ...-40-2000 in horizontal operation
DGP(I)(L)- 40-1500 DGP(I)(L)-40-1750 DGP(I)(L)-40-2000
MPYE-5-1/4-010B MPYE-5-1/4-010B MPYE-5-1/4-010B
Mass [kg] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s]
5 25 23 26 1.12 27 26 27 1.38 28 26 27 1.49
10 27 26 26 1.19 29 28 27 1.34 31 27 27 1.52
15 29 28 26 1.19 31 29 27 1.36 32 29 27 1.55
20 30 29 26 1.20 32 30 27 1.39 33 31 27 1.56
25 31 31 26 1.23 33 31 27 1.39 34 32 27 1.57
30 32 32 26 1.28 33 32 27 1.40 35 33 27 1.63
35 32 33 26 1.30 34 33 27 1.45 35 34 27 1.64
40 33 33 26 1.30 35 34 27 1.47 36 35 27 1.64
45 33 34 26 1.32 35 35 27 1.50 36 36 27 1.70
50 34 35 26 1.37 35 36 27 1.54 37 36 27 1.69
55 34 35 26 1.36 36 36 27 1.55 37 37 27 1.71
60 34 36 26 1.40 36 37 27 1.58 38 38 27 1.77
65 35 36 26 1.42 37 37 27 1.58 38 38 27 1.78
70 35 37 26 1.45 37 38 27 1.62 38 39 27 1.81
75 35 37 26 1.45 37 38 27 1.62 39 39 27 1.83
