2. Parameters of the SPC11 for the DGP(I)(L)-...
2-18
Festo P.BE-SPC11 -DGP-EN en 0012NH
DGP(I)(L)-40-750 to ...-40-1250 in horizontal operation
DGP(I)(L)-40-750 DGP(I)(L)-40-1000 DGP(I)(L)-40-1250
MPYE-5-1/4-010B MPYE-5-1/4-010B MPYE-5-1/4-010B
Mass [kg] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s]
5 18 20 24 0.67 20 21 25 0.83 23 22 26 0.95
10 20 23 24 0.75 23 24 25 0.85 25 25 26 0.98
15 21 25 24 0.78 24 26 25 0.87 27 27 26 1.01
20 22 26 24 0.80 25 29 25 0.96 28 28 26 1.06
25 23 27 24 0.75 26 29 25 0.93 29 30 26 1.07
30 24 28 24 0.79 27 30 25 0.93 30 31 26 1.10
35 25 29 24 0.85 28 30 25 0.94 30 32 26 1.14
40 25 30 24 0.82 28 33 25 1.01 31 32 26 1.14
45 26 31 24 0.87 29 32 25 1.00 31 33 26 1.15
50 26 31 24 0.84 29 33 25 1.01 32 34 26 1.18
55 26 33 24 0.91 30 33 25 1.03 32 34 26 1.19
60 27 32 24 0.91 30 34 25 1.07 32 35 26 1.23
65 27 33 24 0.94 30 34 25 1.07 33 35 26 1.24
70 27 33 24 0.92 31 35 25 1.10 33 36 26 1.26
75 28 34 24 0.96 31 35 25 1.10 33 36 26 1.28
