Festo SPC11 - Page 41

2. Parameters of the SPC11 for the DGP(I)(L)-...
2-9
Festo P.BE-SPC11 -DGP-EN en 0012NH
DGP(I)(L)-25-450 to ...-25-600 in horizontal operation
DGP(I)(L)- 25-450 DGP(I)(L)- 25-500 DGP(I)(L)-25-600
MPYE-5-1/8- H F-010B MPYE-5-1/8- H F-010B MPYE-5-1/8- H F-010B
Mass [kg] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s]
2 13 19 11 0.46 14 19 12 0.47 16 20 12 0.56
4 14 21 11 0.52 15 22 12 0.56 17 22 12 0.63
6 16 23 11 0.55 17 23 12 0.57 19 24 12 0.59
8 17 24 11 0.59 18 25 12 0.58 20 26 12 0.70
10 18 26 11 0.63 19 26 12 0.64 21 27 12 0.69
12 18 28 11 0.63 20 27 12 0.68 22 28 12 0.71
14 19 27 11 0.66 20 28 12 0.65 22 30 12 0.76
16 20 28 11 0.72 21 28 12 0.68 23 29 12 0.76
18 20 29 11 0.68 21 29 12 0.69 23 30 12 0.75
20 21 29 11 0.69 22 30 12 0.75 24 30 12 0.80
22 21 30 11 0.72 22 30 12 0.77 24 31 12 0.83
24 21 30 11 0.72 23 31 12 0.73 25 32 12 0.86
26 22 31 11 0.79 23 31 12 0.82 25 32 12 0.84
28 22 31 11 0.78 23 32 12 0.80 25 32 12 0.85
30 22 32 11 0.76 23 32 12 0.81 25 33 12 0.84
