2. Parameters of the SPC11 for the DGP(I)(L)-...
2-13
Festo P.BE-SPC11 -DGP-EN en 0012NH
DGP(I)(L)-32-450 to ...-32-600 in horizontal operation
DGP(I)(L)- 32-450 DGP(I)(L)- 32-500 DGP(I)(L)-32-600
MPYE-5-1/8- H F-010B MPYE-5-1/8- H F-010B MPYE-5-1/8- H F-010B
Mass [kg] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s]
3 13 17 23 0.54 14 18 23 0.57 16 18 24 0.65
6 15 21 23 0.62 17 20 23 0.60 19 21 24 0.66
9 17 22 23 0.58 18 23 23 0.67 20 24 24 0.75
12 18 24 23 0.65 19 25 23 0.68 21 25 24 0.76
15 19 26 23 0.70 20 25 23 0.70 22 27 24 0.79
18 20 26 23 0.68 21 26 23 0.72 23 28 24 0.76
21 20 27 23 0.67 22 27 23 0.69 24 28 24 0.80
24 21 28 23 0.72 22 30 23 0.78 24 30 24 0.84
27 21 29 23 0.71 23 28 23 0.74 25 29 24 0.76
30 22 28 23 0.67 23 30 23 0.75 25 30 24 0.82
33 22 30 23 0.77 23 30 23 0.79 25 31 24 0.83
36 23 30 23 0.74 24 30 23 0.79 26 32 24 0.90
39 23 31 23 0.72 24 31 23 0.83 26 33 24 0.87
42 23 31 23 0.77 24 32 23 0.82 26 32 24 0.90
45 24 30 23 0.76 25 31 23 0.80 27 32 24 0.86
