Festo SPC11 - Page 46

2. Parameters of the SPC11 for the DGP(I)(L)-...
2-14
Festo P.BE-SPC11 -DGP-EN en 0012NH
DGP(I)(L)-32-750 to ...-32-1250 in horizontal operation
DGP(I)(L)- 32-750 DGP(I)(L)-32-1000 DGP(I)(L)- 32-1250
MPYE-5-1/4-010B MPYE-5-1/4-010B MPYE-5-1/4-010B
Mass [kg] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s] Amplification stage Cushioning stage System parameter Time [s]
3 18 20 22 0.65 19 21 23 0.85 20 22 24 1.03
6 19 22 22 0.72 20 24 23 0.91 22 25 24 1.01
9 20 24 22 0.78 22 26 23 0.92 24 27 24 1.03
12 21 26 22 0.76 23 28 23 0.93 25 29 24 1.10
15 21 27 22 0.81 24 29 23 0.94 26 30 24 1.12
18 22 28 22 0.80 24 30 23 0.94 27 31 24 1.10
21 23 29 22 0.84 25 31 23 1.01 27 32 24 1.18
24 23 30 22 0.85 25 31 23 1.02 28 33 24 1.12
27 24 30 22 0.82 26 32 23 0.99 28 35 24 1.22
30 24 31 22 0.91 26 33 23 1.04 29 34 24 1.20
33 25 31 22 0.85 27 33 23 1.07 29 35 24 1.22
36 25 32 22 0.95 27 34 23 1.05 30 35 24 1.25
39 25 32 22 0.88 28 34 23 1.06 30 36 24 1.28
42 25 33 22 0.93 28 35 23 1.15 30 36 24 1.27
45 26 33 22 0.97 29 35 23 1.12 31 37 24 1.30
