1. Summary of components
1-10
Festo P.BE-SPC11 -DGP-EN en 0012NH
Vertical fitting position
Drive length
ValvetypeMPYE-... Screw connectors for Tube type PUN
in mm
MPYE-... DGP(I)(L)- ...
DGP(I)(L)- 63-...
225 MPYE-5-1/8- LF- 010B QS-1/8-8 QS-3/8-8 PUN- 8x1,25
300 MPYE-5-1/8- H F-010B QS-1/8-8 QS-3/8-8 PUN- 8x1,25
360 to 450 MPYE- 5-1/4-010B QS-1/4-10 QS-3/8-10 PUN-10x1,5
500 to 2000 MPYE-5-3/8- 010B QS-3/8-12 QS-3/8-12 PUN- 12x2
Proportional directional control valve ( 5 )
see System manual type P.BE-SPC11-SYS...
The DGP(I)(L)-... is suitable for both slide operation and yoke
operation. W ork connection 2 of the proportional directional
control valve must be wired to the drive connection on the
same side as the electrical connection for the potentiometer.
