FM350-GL Hardware Guide Page 26 of 67
Parameter
Mode
Condition
Average
Current
(mA)
n48
TBD
n66
TBD
n71
TBD
n77
TBD
n78
TBD
n79
TBD
Note:
The above data is the average value obtained by testing the sample for high/medium/low
channels.
In 5CA/NSA combination, the FM350 power consumption is shown in the following table:
TBD
Note:
The data above is an average value tested on some samples at 25°C temperature.
3.3 Control Signal
The FM350 module provides two control signals for power on/off and reset operations. The pin is defined
in the following table:
Pin
Pin Name
I/O
Reset Value
Function
Level
6
FULL_CARD_POWER
_OFF#
I
PU
Module power on/off input,
internal pull up(350KΩ)
Power on: High/Floating
Power off: Low
3.3/1.8V
67
RESET#
I
PU
WWAN reset input, active low,
internal pull up(350KΩ)
1.8V
50
PERST#
I
PU
Asserted to reset module PCIe
interface default. If module went into
core dump, it will reset whole
module, not only PCIe interface.
Active low, internal pull up(10KΩ)
3.3/1.8V
