FM350-GL Hardware Guide Page 56 of 67
4.6 Antenna Design
The FM350 module provides four antenna interfaces, and the antenna design requirements is shown in
the following table:
FM350 Module Main Antenna Requirement
Frequency range
The most proper antenna to adapt the frequencies should be used.
Bandwidth(WCDMA)
WCDMA band 1 (2100): 250MHz
WCDMA band 2 (1900): 140MHz
WCDMA band 4 (1700): 445MHz
WCDMA band 5 (850): 70MHz
WCDMA band 8 (900): 80MHz
Bandwidth(LTE)
LTE band 1 (2100): 250MHz
LTE band 2 (1900): 140MHz
LTE Band 3 (1800): 170MHz
LTE band 4 (1700): 445MHz
LTE band 5 (850): 70MHz
LTE band 7 (2600): 190MHz
LTE Band 8 (900): 80MHz
LTE band 12 (700): 47MHz
LTE band 13 (700): 41MHz
LTE band 14 (700): 40MHz
LTE band 17 (700): 42MHz
LTE band 18 (800): 80MHz
LTE band 19 (850): 80MHz
LTE band 20 (800): 71MHz
LTE band 25 (1900): 145MHz
LTE band 26 (850): 80MHz
LTE band 28 (700): 100MHz
LTE band 29 (700): 11MHz
LTE band 30 (2300): 55MHz
LTE band 32 (1500): 44MHz
LTE band 34 (2000): 15MHz
LTE band 38 (2600): 50MHz
LTE band 39 (1900): 40MHz
LTE band 40 (2300): 100MHz
LTE band 41 (2500): 110MHz
LTE band 42 (3500): 200MHz
LTE band 43 (3700): 200MHz
LTE band 46 (5500): 775MHz
LTE band 48 (3600): 150MHz
LTE band 66 (1700): 490MHz
LTE band 71 (600): 81MHz
NR
n1 (2100): 250MHz
n2 (1900): 140MHz
n3 (1800): 170MHz
