FT-70/75 Fill Level Inspectors Operator’s Guide
X Industrial Dynamics Company, Ltd. Document 40274-0600
Filtec Model FT-70/75 Radiation Exposure Profiles
X-RAY GAUGE: 45 KV @ 50 µ A with 2 (.015 inch) BeKu Filters
Figure 2. FT-70/75 Radiation Profile Schematic.
4" TO
7.5
"
1
1
2
3
3
4
4
5
5
6
6
7
7&8
8
No. Description No. Description
1 Inspection Head 5 5 cm Isodistance Contour
2 Inspection Tunnel 6 Radiation Detector
3 Sealed X-ray Source 7 Shielding Bar (1/4” Thick Steel)
4 Limits of Main Beam 8 Detector Window
