Chapter 2: Operating Your FT-70/75
2-11
Aligning the High Cap Sensor
Figure 2-5. Aligning the High Cap Sensor
6
1
2
3
4
5
8
7
No. Description
1 Sensor Emitter
2 Height Adjustment Lock
3 Container Cap
4 Sensor beam
5 Sensor Receiver
6 Container Travel
7 Distance between Container Cap and Sensor Beam
8 Secondary Sensor Height Adjustment
Industrial Dynamics Company, Ltd. Document 40274-0600
