FT-70/75 Fill Level Inspectors Operator’s Guide
2-14
Caution
Do not use the Smashed Bottle function to detect the container
base only. If the container is smashed down to the base it cannot be
rejected properly and may damage the rejector.
3. Loosen the upstream sensor mounting bracket adjustment
knob and adjust the sensor so that it contacts the bottle 1mm-2
mm below the point where the container is smashed.
Note
If you do not have enough adjustment range to position the sensor
correctly, reposition the sensor receiver and emitter in the bracket
by moving it up or down enough hole positions to give you the
range you need.
4. Tighten the adjustment knob to secure the positioning.
5. If you will not be performing further alignment procedures,
reactivate the X-ray Generator. For more information see “The
Safety Interlock Switch” on page 2-4.
Industrial Dynamics Company, Ltd. Document 40274-0600
