17
Careful maintenance of the squeegee rubbers guarantees better
cleaning and drying of the oor, as well as a longer vacuum motor
life. To replace the squeegee rubbers, proceed as follows:
• Turn the wing nuts (28) that hold the squeegee by 90°
(Fig.33).
• Remove the squeegee from the slots on the squeegee
connector, taking care not to lose the seal on the vacuum
nozzle (Fig.34).
• Replace the worn/damaged rubber.
• Repeat the operations in reverse order to reassemble all the
parts.
36. Bring the squeegee coupling to the idle position and shift the
squeegee towards the appliance (Fig.35).
37. Fix the squeegee coupling in the idle position. Push the knob (22)
towards the appliance (Fig.36), then rotate it in the direction of
the arrow (Fig.38).
ATTENTION: Fig.37 shows the left side of the device. Rotate
the knob on the right-hand side in the opposite direction.
38. Remove the exhaust air lter support (29) from the appliance by
pressing the xing tab (30) in the direction of the arrow (Fig.38).
39. Clean the lter cartridges (31) with a jet of air (Fig.39), from a
distance of at least 20 cm.
Careful maintenance of the exhaust air lters guarantees a longer
vacuum motor life. To replace the lter cartridges, proceed as
follows:
• Remove the lter cartridge supports (32) from the lter
support (Fig.40).
• Remove the worn lter cartridge (31) from the lter cartridge
support (32) and replace it with the new one (Fig.41).
• Repeat the operations in reverse order to reassemble all the
parts.
40. Insert the exhaust air lter support (29) in the appliance (Fig.42).
41. Rotate the appliance to its work position (Fig.43).
42. Block the handlebar in the vertical position; to release the
handlebar, move the stop (33) in the direction of the arrow
(Fig.44).
43. Rotate the front carter (4) as far as it will go - do this with the aid
of the handle (5) (Fig.45).
44. Insert the two tanks and the detergent solution lter cartridge
in the appliance, positioning rst the detergent solution lter
cartridge, then the solution tank, and nally the recovery tank.
45. Rotate the front carter (4) as far as the work position - do this with
the aid of the handle (5) (Fig.46).
46. Insert the battery in the battery-holder compartment in the rear
part of the appliance (Fig.47).
47. Position the appliance with its rear part in contact with the oor
(Fig.48).
ATTENTION: park the appliance in an enclosed place, on a
at surface; near the appliance there must be no objects that
could either damage it, or be damaged through contact with it.
