BB302 MU2018 Rev B
69
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
HYDRAULIC PARTS
Ref. No. Part Number Description No. Req’d
26 055837-06 1/4 in. Working Hose X 26 in. OAL 1
27 FW71450 1/4 in. MNPT X #4 MJIC 90° Elbow 1
28 055598 1/4 in. MNPT X #4 MJIC 90° LL Elbow 1
29 005686 #10 MSAE X #4 FJIC Reducer 2
30 055698 Hydraulic Motor, Feed/Floor 1
31 055820 Hydraulic Reservoir 1
32 080329 Sight Gauge, Reservoir 1
33 055599 3/4 in. MNPT X #12 MJIC 90° LL Elbow 1
34 005793 Filler Breather, Hydraulic 1
35 055837-09 3/4 in. Return Hose X 56 in. OAL 1
36 055233 #8 MSAE X #12 MJIC Straight Fitting 1
37 023913 Filter Assembly, Hydraulic 1
023914 Cartridge, Filter 1 per
38 008689 #8 MSAE X #8 MJIC X #8 MJIC Tee Fitting 1
39 055868 #6 FJIC X #6 MJIC Reducer 1
40 FW71448 #6 MSAE X #6 MJIC 90° Elbow 1
41 055837-05 3/8 in. Return Hose X 69 in. OAL 1
42 055357 #8 FJIC Swivel X #8 MJIC Straight Fitting 1
43 055659 Switch, Pressure 1
44 055601 #6 MSAE X #6 MJIC Straight Fitting 2
45 055855 Manifold, Rotary Air Valve 1
A 055855-01 Machined Rotary Air Valve Manifold Block 1
B 055855-02 Relief Valve 1
C 055864 4-Way Solenoid Valve 1
075919 Solenoid Coil 2 per
055866 Solenoid Coil Nut 2 per
46 FW71609 1/4 in. FNPT X 1/4 in. MNPT 45° Elbow 1
47 055837-04 3/8 in. Working Hose X 41 in. OAL 2
48 055741 #10 MSAE X #6 MJIC 45° Elbow 2
49 055552 Motor, Airlock Hydraulic 1
055517 Hydraulic Motor Gasket 1 per
50 005619 Pipe Clamp 1
51 055882 Suction Pipe Support Bracket 1
To Next Page
