PRIOR TO APPLICATION
1. Operator should familiarize themselves with the area to be seeded and develop a plan to
ensure uniform application.
2. Develop a plan for communication between operator and driver of the carrying or towing
vehicle to signal for start, stop, turn, etc. through the use of the signal horn.
3. Operator takes up position on the platform. From this point, application will be controlled by
the use of the clutch, valve, discharge assembly, and throttle.
DISCHARGE NOZZLE SELECTION
Nozzles are stored in the tool box. This HydroSeeder
®
is equipped with six nozzles – two long
distance and four fan nozzles. The smaller long distance nozzle is generally better suited for seed,
fertilizer, and/or lime application while the large long distance nozzle is better for wood fiber mulch
application. All of the fan nozzles are generally suited for both types of application.
Nozzle Part Number Distance (A) Width (B) T330 Discharge Time
Lg. Long Distance 011775 Up to 230 ft (70 m) 7.5 min.
Sm. Long Distance 011703 Up to 150 ft (46 m) 30 min.
Sm. Narrow Fan 011707 Up to 75 ft (23 m) 15 ft (4.6 m) 30 min.
Sm. Wide Fan 011706 Up to 45 ft (14 m) 25 ft (7.6 m) 30 min.
Lg. Narrow Fan 011891 Up to 90 ft (28 m) 23 ft (7 m) 10.6 min.
Lg. Wide Fan 011890 Up to 50 ft (15 m) 35 ft (10.5 m) 10.6 min.
NOTE: T280 discharge times will be slightly shorter.
A
B
Figure 15 – Nozzle Spray Dimensions
