T280 / T330 / T400
MMA2017 Rev. D
67
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
CLUMP, PIPING, AND DISCHARGE ASSEMBLY
Ref. No. Part Number Description No. Required
1 011736 5 in. Victaulic Pipe Clamp 4
2 011919 Seal For 5 in. Victaulic Pipe Clamp 1 per
3 008259 5 in. Dia x 90º Pipe Elbow 1
4 0X1232 3/4-10 Hex Bolt 16
5 012722 Suction Valve Flange Weldment 2
6 012058 5 in. Flanged Suction Gate Valve 1
7 012491 Suction Valve Bleeder Valve Assembly 1
8 012491-02 Suction Elbow Weldment 1 per
9 012457 1/2 in. Dia. Stainless Steel Ball Valve 1 per
10 160428 1/2 in. Dia. x 4 in. Lg. SCH 40 Nipple 1 per
11 160006 1/2 in. Dia. x 90º Elbow 1 per
12 011787 Pump Discharge Gasket 1
13 012761 Pump Flange Weldment 1
14 002771 2-1/2 in. Victaulic Pipe Clamp 3
15 002820 Seal For 2-1/2 in. Victaulic Pipe Clamp 1 per
16 012809 Lower Discharge Pipe 1
17 012724 Discharge Valve Stand Pipe 1
18 160263 1-1/2 in. Dia. Pipe Cap 1
19 011727-09 Recirculation Nozzle 1
20 006721 1-1/4 in. Victaulic Pipe Clamp 3
21 006722 Seal For 1-1/4 in. Victaulic Pipe Clamp 1 per
22 011727-10 Recirculation Nozzle 1
23 011776 1-1/4 in. Round Port 2-Way Valve 1
24 012786 Recirculation Lever 1 per
25 004962 Lube Screw 1 per
26 011950 Gasket For 1-1/4 in. Valve 1 per
27 011951 Spring For 1-1/4 in. Valve 1 per
28 011727-11 Recirculation Nozzle 1
29 012726-03 Recirculation Pipe 1
30 012462-05 Recirculation Pipe Seal/Coupling 1
31 005703-02 1-1/4 in. Coupling Deflector 1
32 011777 2-1/2 in. Round Port 2-Way Valve 1
33 011953 Spring 1
34 008487 Gasket 1
35 004962 Lube Screw 1
36 012758 Valve Foot Pedal 1
37 011882 2-1/2 in. SCH 40 x 3 in. Toe-Goe Pipe 1
38 F330-0090 Recirculation Valve Stabilizer 1
