Finn HydroSeeder T280 - Air Intake and Exhaust Systems

T280 / T330 / T400
MMA2017 Rev. D
63
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
AIR INTAKE AND EXHAUST SYSTEM
Ref. No. Part Number Description No. Required
1 JDRC400 Rain Cap 1
2 013176 4 in. 60° Exhaust Elbow 1
3 055336 4 in. Muffler Clamp 1
4 013174 Exhaust Elbow Weldment 1
5 013178 Muffler Mounting Bracket 1
6 JDP206602 4 in. Exhaust Clamp 1
7 JD94100-0256 2.56 in. T-Bar Clamp 6
8 JDP532949 2.25 in. Silicone Hose 2
9 JDR128455 Upper Radiator Hose 1
10 JD32-H Hose Clamp 1
11 JD50-0073 Upper Radiator Pipe 1
12 JDP148337 2 in. T-Bolt Clamp 2
13 JDR135730 2 in. x 2.25 in. x 3 in. Hose Adapter 2
14 JD28-H Hose Clamp 2
15 055335 4 in. Air Intake Clamp 1
16 325075 Reducing Elbow 1
17 055496 3 in. Air Intake Clamp 3
18 013183 Air Cleaner Tube 1
19 011852 3 in. 90° Rubber Elbow 1
20 F330-0144 Air Cleaner Mount 1
21 013135 Air Cleaner Assembly 1
013135-M Main Filter 1
013135-S Safety Filter 1
22 JD50-0265 Lower Radiator Pipe 1
NOT SHOWN
JDR128475 Lower Radiator Hose 1
JD28-H Hose Clamp (See Above)
JD36-H Hose Clamp (See Above)
