T280 / T330 / T400
MMA2017 Rev. D
73
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
BOOM LEVEL CONTROLS
Ref. No. Part Number Description No. Required
1 011785 Agitator Control Assembly 1
2 011954 Black Knob - 1-3/16 in. Dia. 1 per
3 013223 T330 Tier III Control Box Assembly 1
4 004996 1 in. Pipe Plug 1
5 012777 Recirculation Handle 1
6 F330-0102 Agitator Control Box 1
7 012780-05 Recirculation Valve Rod Assembly 1
8 006737 Ball Joint 2 per
9 012493-02 Bleeder Valve Handle 1
10 012493-09 Handle Bearing Pad 1
11 012780-02 Clutch Rod Assembly 1
12 006737 Ball Joint 2 per
13 000427 Black Handle Grip 1
14 012760 Clutch Handle 1
15 F330-0095 Control Box Mount 1
16 085148 U-Bolt 1
17 031245 Snapper Pin 1
18 005700 Lanyard 1
19 F330-0081 Boom Holddown 1
20 006596 Agitator Control Cable 1
21 007675 Ball Joint 2
22 004983 Clamp and Shim 1
23 007913 Rubber Strap w/ S-Hooks 1
