LUBRICATION AND FLUIDS CHART
Ref. No. Location Lubricant Frequency Number
1 Check Grease Level in Pressure Lubricator BL Daily 1
2 Check Clutch Lever Bearings CL Weekly 2
3 Grease Agitator Shaft Bearings CL Daily 4
4 Check Fuel Level DF Daily 1
5 Grease Discharge Swivels CL Daily 2
6 Check Engine Oil Level MO Daily 1
7 Check Engine Oil and Filter MO See Engine Manual 1
8 Grease Pump Bearings BL Weekly 2
9 Check Hydraulic Fluid Level HO Weekly 1
Change Hydraulic Fluid and Filter HO Seasonally or 500 Hours 1
10 Grease Discharge and Recirculation Valves SL Each Load 2
11 Grease Valve Arm Lever CL Weekly 1
12 Change Engine Coolant AF Seasonally 1
13 Remove Muffler Drain Plug - Seasonally 1
FLUID CAPACITIES
Fuel – 38 gal (144 L)
Hydraulic Oil – 50 gal (189 L)
Engine Coolant – 4.25 gal (16 L) 50/50 Mix Only
Engine Oil – See Engine Manual
LUBRICANT OR FLUID USED
BL Bearing Lube (Sodium-Based)
CL Chassis Lubricant
MO See Engine Manual
HO Mobil DTE-13M or Equivalent Hydraulic Oil
SL Special Stick Lubricant
AF 50/50 Anti Freeze and Water Mixture
DF Diesel Fuel
TIME KEY
DAILY (8 Hours)
WEEKLY (40 Hours)
EACH LOAD
SEASONALLY (500 Hours)
SEE ENGINE MANUAL
