T280 / T330 / T400
MMA2017 Rev. D
75
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
CONTROL BOX WIRING
Part Number Description No. Required
013121 Control Box Assembly
012774 Control Box Wiring
012743 Modified Control Box 1
012742 Modified Subpanel 1
012739 PowerView 1
023892 PowerView Cable 1
052118 6 Circuit Fuse Panel 1
012727 Throttle Control Card 1
012784 1-1/2 in. Hole Plug 1
080526 Switch Boot 2
022425 Diode 1
020886 Horn Button 2
052076 Ignition Switch 1
023076 Key for Ignition Switch 1
055449 10 Amp Fuse 5
FW71555 Toggle Switch 2
FW71749-02 30 Amp Relay 3
012839 3/4 in. Conduit Hole Plug - Gray w/ Seal 1
080304 Liquid Tight Fitting 1
FW71612 Cord Connector with Locknut 1
170028 30 Amp In-Line Fuse and Holder 1
To Next Page
