Finn HydroSeeder T280 - Page 70

T280 / T330 / T400
MMA2017 Rev. D
64
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
STARTER
RELAY
STARTER
ALTERNATOR
B+
D+
(Red)
+
-
WIRES FROM
DEERE HARNESS
(Red)
(Yellow)
(Black)
(Black)
(Red)
(Black) Battery Cable
(Red)
(Orange) From
Deere Harness
(Red) Battery Cable
OIL COOLER FAN
(Black)
(Blue)
(Blue-12)
To
Engine
To
Frame
1
2
3
4
5
6
7
