Chapter 4 . Har dware Assembly
The Dreamer comes pre-assembled and is almost ready-to-print (ARP). All you need
to do is to mount the extruder set, and install the filament. It will only take 5 to 10
minutes to start up the Dreamer and prepare for your first 3D print!
4.1 Mounting the Extruder Set
4-1
(4-1) Lay the extruder module on the top of the extruder support with the two extruder
fans facing the front.
(4-2) Fix the extruder module onto the extruder support with two M3*12 screws from
the bottom up.
4-2
