14 Data Logger and Transmission of Data FLUXUS G80x
UMFLUXUS_G8V4-6-1EN, 2018-10-10 103
14.2.7 Offline Transmission of Data with the Program FluxData
The measurement data in the data logger are transmitted to a PC via the serial interface RS232 with the FLEXIM program
FluxData.
Settings in the Program
Start the program FluxData V3.0 or higher on the PC.
Select the menu:
Options > Serial interface.
Select the serial interface used from the PC (e.g., COM1).
Click Protocol.
Click OK.
Enter the transmission parameters (see section 14.2.4). If the
default settings of the transmission parameters are to be used,
click Default protocol.
The transmission parameters of FluxData and transmitter have
to be identical.
Click OK.
Transmission of Data
Select the menu:
DUT > Receive measuring values.
Wait until the data are transmitted.
