FT-112(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 101 of 170
THR-LOW Threshold, active low
Output goes to low if net weight is
heavier than setpoint high. Returns the
high if the weight is less than setpoint
low.
VIN-HI Window, active high
Output goes to high if net weight is
between setpoint high and setpoint low.
VIN-LOW Window, active low
Output goes to low if net weight is
between setpoint high and setpoint low.
