FT-112(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 110 of 170
Fast Continuous Data Output
Fast continuous “indicated weight” data output can be used only for the instruments, which can communicate
fast. The output rate is related with the baud rate. Use higher baud rate for faster data rate. CR and LF can be
enabled. You may reduce the data transfer speed by increasing the delay between data output packages.
The data format of the fast-continuous data output is;
[STX][STATUS][SIGN][WEIGHT VALUE][CR][LF]
Examples:
S+000123.4 (weight is stable and 123.4)
D+000123.4 (weight is unstable and 123.4)
M+000123.4 (Dynamic weighing result is 123.4)
------------- (Dynamic weighing in calculating)
+ (Over load)
- (Under load)
O (ADC out error)
Print Mode
The format of the data output in Print mode can be selected in 5 different type forms in the sub-block 16- .
Only one serial port can be programmed for printing. Print mode data outputs is sent by pressing the key
or by receiving ASCII P command via serial port, or via Ethernet port by setting remote IP and remote port
number, refer to parameter 19E and 19F.
SINGLE LINE
You can transmit the printout data in single line format by pressing key. This format is recommended to
send the print data to PC or to any host. The data output structure is;
12.02.2016 14:47 CN: 71 G: 3.007kg T: 1.001kg N: 2.006kg *ALB: 5*
MULTI LINE
You can send the data in multiple line formats as shown in the label given below by pressing key. The
data output including can be programmed with printer parameters. The multiline data output can be
programmed for 16-byte narrow printers and for others.
Format for 16-character printer:
