FT-112(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 151 of 170
Expanded Command List
Here 1
st
Dword (Input) is the data receiving from PLC and the “B23 … B16” bits describe below.
Bit No
Description
B23…B16
Expanded
Command
s List
Bin
De
c
Commands
00000000
0
R
Voltage of power supply
(2)
The value is indicated with 0.1 VDC increment
for DC variant.
00000001
1
R
Load cell millivolt value
(2)
(Only FT-112(D) Panel)
Millivolt of active scale is indicated with 0.01
mV increment.
00000010
2
R
Command
status
(2)
De
c
Descr. of 1st Dword
0
None
1
Command is processing
2
Command is done
3
Command failed
00000011
3
R/
W
Reprint the last
label
(1) (2)
0
None
1
Reprint the last label
00000100
4
R/
W
High resolution
(1)
(2)
0
Enable
1
Disable
00000101
5
W
Unit change
(1)
0
From first to second unit
1
From second to first unit
00000110
6
R/
W
Key lock
(1) (2)
0
Enable
1
Disable
00000111
7
W
Dynamic
operation
(1)
0
Dynamic reset
1
Dynamic start
00001000
8
W
Totalization
operation
(1)
0
None
1
M+ key
2
Totalization Print
3
Totalization Cancel
00001001
9
W
SmartAPP
operation
(1)
0
Reset
1
Start
00001010
00001011
10
11
Not used
00001100
12
R/
W
Basic Peak
0
Enable
1
Disable
00001101
13
R/
W
Hold
0
Enable
1
Disable
00001110
00110100
14
52
Not used
00110101
53
R
1
st
Peak value
(2)
Only available for
Peak hold application.
Refer to Section 10.4, page88.
00110110
54
R
2
nd
Peak value
(2)
00110111
55
R
3
rd
Peak value
(2)
00111000
56
R
4
th
Peak value
(2)
00111001
57
R
5
th
Peak value
(2)
00111010
58
R
6
th
Peak value
(2)
00111011
59
R
7
th
Peak value
(2)
00111100
60
R
8
th
Peak value
(2)
00111101
61
R
9
th
Peak value
(2)
00111110
62
R
10
th
Peak value
(2)
00111111
63
R/
W
Dynamic filter
(1) (2)
Refer to par. 332 page 59
01000000
64
R/
W
Filter
(1) (2)
0
No
1
Very Low
2
Low
3
Medium
4
High
