PLC Output to FT-112(D) Panel Input
Bitwise of a Dword:
Unsigned
Long
(R/W)
B63
B62
B61
B60
B59
B58
B57
B56
B55
B54
B53
B52
B51
B50
B49
B48
B47
B46
B45
B44
B43
B42
B41
B40
B39
B38
B37
B36
B35
B34
B33
B32
B31
B30
B29
B28
B27
B26
B25
B24
B23
B22
B21
B20
B19
B18
B17
B16
B15
B14
B13
B12
B11
B10
B9
B8
B7
B6
B5
B4
B3
B2
B1
B0
RxPDO 1
(R_UL1)
Out
5
Out
4
Out
3
Out
2
Out
1
Expanded Commands List
Not in use
Command List
Read Data Selection
New
CMD
B37-B33 bits defines the usage of this Dword.
PLC Output to FT-112(D) Panel Input RxPDO 1 (R_UL1)
Bit
Number
RxPDO 1 (R_UL1) descriptions
B63 …
B56
Set / Reset digital outputs
B55 …
B48
Expanded Commands List (Refer to Table 16-3)
B47 …
B43
Not in use
B42 …
B38
Command
List
Bin
Dec
Commands
00000
0
None command is activated
00001
1
Zero
00010
2
Tare
00011
3
Clear
00100
4
Print
00101
5
Adjust zero calibration
Calibration
00110
6
Adjust span calibration
(1)
00111
7
Total Load Cell Capacity
(1)
eCal
Coefficients
Refer to par. [613]
01000
8
Average mV/V value
(1)
01001
9
Dead Load value
(1)
01010
10
Save the coefficients of eCal
01011
11
CN (Label number)
(1)
01100
12
Preset Tare
(1)
01101
13
Grand Total
01110
14
Not used
01111
15
B. weighing
Filling
C.weighing
Classifying
Peak hold
Set Point-
1
Target
Target
Target
Follow
10000
16
Set Point-
2
Coarse
Low
--Low
Mid
Decr.
10001
17
Set Point-
3
Fine
High
-Low
End
Decr.
10010
18
Set Point-
4
TareMin
Empty
+High
Stop
10011
19
Set Point-
5
TareMax
Not used
++High
Alarm
