FT-112(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 160 of 170
10100
20
Not used
Empty
Not used
Empty
Empty
10101
21
SetPoint-1 Low
Only available for Threshold and
Window feature.
Refer to sub-block 36-, page 61 to see
the availabilities.
10110
22
SetPoint-2 Low
10111
23
SetPoint-3 Low
11000
24
SetPoint-4 Low
11001
25
SetPoint-5 Low
11010
11110
26
30
Not used
11111
31
Use the Expanded Command list
(Refer to Table 16-3)
B37 ...
B33
Read Data
Selection
00000
0
Actual weight (if the indication is in Net)
00001
1
Gross weight
00010
2
Tare weight
00011
3
ALL Status (Refer to Table 16-1)
00100
4
Calibration Status (Refer to Table 16-2)
00101
5
Last print value
00110
6
Quantity of M+
00111
01010
7
10
Not used
01011
11
CN (Label number)
01100
12
Quantity of M+
01101
13
Grand Total
01110
14
Not used
01111
15
B. weighing
Filling
C.weighing
Classifying
Peak hold
Set Point-
1
Target
Target
Target
Follow
10000
16
Set Point-
2
Coarse
Low
--Low
Mid Decr.
10001
17
Set Point-
3
Fine
High
-Low
End
Decr.
10010
18
Set Point-
4
TareMin
Empty
+High
Stop
10011
19
Set Point-
5
TareMax
Not used
++High
Alarm
10100
20
Not used
Empty
Not used
Empty
Empty
10101
21
SetPoint-1 Low
Only available for Threshold and
Window feature.
Refer to sub-block 36-, page 61 to see
the availabilities.
10110
22
SetPoint-2 Low
10111
23
SetPoint-3 Low
11000
24
SetPoint-4 Low
11001
25
SetPoint-5 Low
11010
11110
26
30
Not used
11111
31
Use the Expanded Command list
(Refer to Table 16-3)
B32
New CMD
Toggle
Apply commands which are listed in this table.
B31-B0
B37-B33 bits defines the usage of this Dword.
(1) Write this command after writing values to Low Dword of RxPDO then apply this command with New
CMD.
