15.7
Deleting
all
images
General
Y
ou
can
delete
all
images
in
a
folder
.
Procedure
Follow
this
procedure
to
delete
an
image:
Push
.
1
Push
the
navigation
pad
up/down
or
left/right
to
select
any
image.
2
Push
to
display
the
image.
3
Push
to
display
a
menu.
4
On
the
menu,
select
Delete
all
and
confirm
the
choice.
5
38
Publ.
No.
T559597
Rev
.
a554
–
ENGLISH
(EN)
–
September
27,
2011
15
–
Working
with
images
49
51
